Technical Specifications
|
Switch Operating Layer:
|
Layer 3 |
|
Firmware/OS:
|
UniFi OS |
|
Management Interface:
|
UniFi Controller |
|
Number of 10/100/1000 Ethernet ports:
|
48 |
|
Optical (SFP/SFP+) Ports:
|
4x10G SFP+ |
|
Serial Port:
|
- |
|
Max. Switching Capacity:
|
224 Gbps |
|
Forwarding Rate:
|
167 Mpps |
|
Number of PoE ports:
|
48 pc |
|
PoE Interfaces:
|
32 PoE+; 16 PoE++ |
|
PoE Standards:
i
|
IEEE 802.3af/at/bt |
|
Max. PoE Power Per Port:
|
32 W |
|
Total PoE Power Budget:
|
720 W |
|
Mac Table Capacity:
|
32 K |
|
Cooling Type:
|
Passive Cooling |
|
Redundant Power Supply:
|
✓ |
|
Power Method:
|
AC 100-240 |
|
Form Factor:
|
Rack-Mount |
|
Maximum Power Consumption:
|
820 W |
|
Operating temperature:
|
-5 °C .. 40 °C |
